SB 2
Compact multifunctional frame to accommodate modern understock care systems.
- Modern
- Compact
- Versatile
Mounting options
Ideal frame to accommodate the modern undervine care systems RADIUS SL, RADIUS SL PLUS or MULTICLEAN. The frame can be combined for rear or front mounting. The SB2 is available for working widths from 68.5 inches to 126 inches – depending on the equipment. The adjustment to the row width is done hydraulically.
Media gallery Photos & videos
About the product More info
Oscillating three-point frame
With the oscillating three-point frame, the SB2 tool carrier can be used either in the front or rear of the tractor without having to convert the attachments. A bolt allows two adjustment positions: Rigid or oscillating.
Mechanical extension
An additional lateral extension of 4 or 8 inches per side is mechanically mounted to the frame.
Side slope correction
Available in hydraulic or mechanical version
Lateral angle adjustment
To compensate for side slopes, we offer hydraulic, mechanical or sensory solutions that bring the weeding device back into the correct position. The lateral angle adjustment can be attached to the base frames such as HEXAGON, SB frames or also to the S2R and S5 column lifters.
Soil and stone deflector
As an option, soil and stone deflectors can be fitted behind the RADIUS, which pushes the stones and soil out of the alley back towards the vine area after weeding. This keeps the vegetation free for follow-up work such as mulching.
Pump-Tank-Unit
Additional hydraulic supply, which is mounted directly on the frame. Hydraulically operated work tools can thus be used without loading the hydraulic system of your tractor.
Column lifter S5
Compact and robust attachment Option for attachments in the mid mount area.
COMPACT lifter
The double-sided operation of machines for undervine care is usually unproblematic. Although sometimes it is...
| Hydraulic requirement: | 1x double-acting |
| Weight without attachments: | about 386 lbs |
| Length x width x height: | about 27.6 x 41,3 x 29,1 in (Outside edges of bars) |
| Three-point category: | Cat. 1 |
